Lixel L2 Pro High Precision 3D Handheld Laser Scanner Real Time Scanning Modeling
Place of Origin:China
Brand Name:TBNET
Model Number:L2 PRO
Minimum Order Quantity:1
Payment Terms:T/T
Tags:
Product Details
Highlight:
High Precision Handheld Laser Scanner
,Real Time Scanning Handheld Laser Scanner
,Precision 3D Handheld Laser Scanner
Working Range:
0.5m~120m
Laser Class:
Class 1 / 905nm
Laser FOV:
360°×270°
Handheld Weight:
<1.6kg
Relative Accuracy:
±1.2cm
Absolute Accuracy:
≤3cm
Repeat Accuracy:
≤2cm
Product Description
Lixel L2 Pro High-Precision Real-Time Scanning & Modeling Device
The Lixel L2 Pro (16/120 version) is a cutting-edge 3D scanning and reconstruction device developed by XGRIDS. Equipped with advanced modules including LiDAR, 3-color cameras, high-precision inertial navigation, and a high-performance computer, the Lixel L2 Pro offers seamless data capture and real-time 3D modeling. This device creates true-color point cloud models with centimeter-level accuracy, providing a powerful solution for precise on-site 3D reconstruction.
Key Features:
Ideal for Complex Scene Modeling: Perfect for large-scale, intricate scene modeling, where high detail and precision are required.
Real-Time True-Color Data: Achieves real-time color data, comparable to post-processing, enabling instant modeling without delays.
High-Accuracy Point Cloud Generation: Produces dense point clouds with 1mm spacing, ensuring precise line drawing and accurate mapping for detailed analysis.
|
|
|
|
Output point clouds directly without any other devices | Modeling while scanning, deliver what you see and scan | Top-tier point cloud quality | Cope with various complicated scenes |
Application Scenarios
|
|
|
Land Survey | Engineering Survey | Urban Renewal |
|
|
|
Minning Survey | Agriculture & Forestry | Emergency Survey |
Software
|
|
An all-in-one 3D post-processing software that offers a range of features, including point cloud | Mobile-controlled operational workflow, real-time preview of scan results, and one-screen monitoring of device status. |
Specification
| Working Range | 0.5m~120m | Handheld Weight | <1.6kg |
| Laser Class | Class 1 / 905nm | Visual-Aided Positioning | Supported |
| Laser FOV | 360°×270° | Real-Time Colored Point Cloud | Supported |
| Processing Mode | Real-time/Post-processing | 5G Real-Time Transmission | Supported |
| Scan Speed | 320,000 points/s | RTK Fusion | Supported |
| Operating Temperature | -20°~50° | Resume Scanning from Breakpoint | Supported |
| Power Consumption | <30W | Point Cloud Format | .Las |
| Storage Capacity | 1TB | Relative Accuracy | ±1.2cm |
| Operating Time | 1.5h | Absolute Accuracy | ≤3cm |
| Protection Level | IP54 | Repeat Accuracy | ≤2cm |
| Horizontal Accuracy | ≤0.015° | Battery Capacity | 46.8wh |
| Cameras | 3 | RTK Frequency | BDS: B1I,B2I,B3I GPS: 1C/A,L2P (Y) /2C,L5 GLONASS: L1 L2 Galileo: E1,E5a,E5b |
| Power Supply | Fast-lock battery/External power |
Product Summary
Lixel L2 Pro High-Precision Real-Time Scanning & Modeling DeviceThe Lixel L2 Pro (16/120 version) is a cutting-edge 3D scanning and reconstruction device developed by XGRIDS. Equipped with advanced modules including LiDAR, 3-color cameras, high-precision inertial navigation, and a high-performance ...
