L2 PRO 3D Laser Scanning Equipment Reconstruction Device For Terrain Surveying

Place of Origin:CHINA
Brand Name:TBNET
Model Number:L2 PRO
Minimum Order Quantity:1
Payment Terms:T/T
Product Details
Highlight:

Handheld 3D Laser Scanning Equipment

,

L2 PRO 3D Laser Scanning Equipment

,

Terrain Surveying 3D Laser Scanning Equipment
Working Range: 0.5m~120m
Laser Class: Class 1 / 905nm
Laser FOV: 360°×270°
Relative Accuracy: ±1.2cm
Absolute Accuracy: ≤3cm
Repeat Accuracy: ≤2cm
Product Description
Real-time Modeling, Realistic Color

The Lixel L2 Pro (16/120 version) is an advanced 3D scanning and reconstruction device by XGRIDS. Equipped with cutting-edge modules, including LiDAR, 3-color cameras, high-precision inertial navigation, and a high-performance computer, the Lixel L2 Pro delivers seamless data capture and real-time modeling. It creates true-color point cloud models with centimeter-level precision, offering a powerful tool for precise 3D reconstruction on the spot.

L2 PRO High-Precision Real-Time Scanning & Modeling Device
Ideal for large-scale, complex scene modeling
Achieves real-time true-color data comparable to post-processing, enabling instant modeling
Generates dense point clouds with 1mm spacing for highly accurate line drawing and mapping



Main Applications of the L2 PRO:

Terrain Surveying

Engineering Surveying

Mining Exploration

Urban Renewal

L2 PRO 3D Laser Scanning Equipment Reconstruction Device For Terrain Surveying 0

L2 PRO 3D Laser Scanning Equipment Reconstruction Device For Terrain Surveying 1

L2 PRO 3D Laser Scanning Equipment Reconstruction Device For Terrain Surveying 2

L2 PRO 3D Laser Scanning Equipment Reconstruction Device For Terrain Surveying 3

Output point clouds directly without any other devices

Modeling while scanning, deliver what you see and scan

Top-tier point cloud quality

Cope with various complicated scenes
Application Scenarios

L2 PRO 3D Laser Scanning Equipment Reconstruction Device For Terrain Surveying 4

L2 PRO 3D Laser Scanning Equipment Reconstruction Device For Terrain Surveying 5

L2 PRO 3D Laser Scanning Equipment Reconstruction Device For Terrain Surveying 6

Land Survey

Engineering Survey

Urban Renewal

L2 PRO 3D Laser Scanning Equipment Reconstruction Device For Terrain Surveying 7

L2 PRO 3D Laser Scanning Equipment Reconstruction Device For Terrain Surveying 8

L2 PRO 3D Laser Scanning Equipment Reconstruction Device For Terrain Surveying 9

Minning Survey

Agriculture & Forestry

Emergency Survey
Software

L2 PRO 3D Laser Scanning Equipment Reconstruction Device For Terrain Surveying 10



L2 PRO 3D Laser Scanning Equipment Reconstruction Device For Terrain Surveying 11

An all-in-one 3D post-processing software that offers a range of features, including point cloud

viewing, editing, model generation, and post-processing.

Mobile-controlled operational workflow, real-time preview of scan results, and one-screen monitoring of device status.
Specification
Working Range 0.5m~120m Handheld Weight <1.6kg
Laser Class Class 1 / 905nm Visual-Aided Positioning Supported
Laser FOV 360°×270° Real-Time Colored Point Cloud Supported
Processing Mode Real-time/Post-processing 5G Real-Time Transmission Supported
Scan Speed 320,000 points/s RTK Fusion Supported
Operating Temperature -20°~50° Resume Scanning from Breakpoint Supported
Power Consumption <30W Point Cloud Format .Las
Storage Capacity 1TB Relative Accuracy ±1.2cm
Operating Time 1.5h Absolute Accuracy ≤3cm
Protection Level IP54 Repeat Accuracy ≤2cm
Horizontal Accuracy ≤0.015° Battery Capacity 46.8wh
Cameras 3 RTK Frequency BDS: B1I,B2I,B3I
GPS: 1C/A,L2P (Y)
/2C,L5
GLONASS: L1 L2
Galileo: E1,E5a,E5b
Power Supply Fast-lock battery/External power
Product Summary

Real-time Modeling, Realistic Color The Lixel L2 Pro (16/120 version) is an advanced 3D scanning and reconstruction device by XGRIDS. Equipped with cutting-edge modules, including LiDAR, 3-color cameras, high-precision inertial navigation, and a high-performance computer, the Lixel L2 Pro delivers ...
