PandaNRTK Network RTK System Management Platform

Place of Origin:China

Brand Name:Panda

Product Details

Highlight:

PandaNRTK RTK system platform

GNSS receiver management system

Network RTK system with warranty

Real-Time Precise Positioning Accuracy: Horizontal: Better Than 3cm, Vertical: Better Than 5cm

Navigation Accuracy: 1-2m

Service Availability: >99%

Real-Time Precise Positioning: Within The Regional Reference Station Network (station Spacing <70km) And Up To 30km Outside The Network

Navigation Positioning: Within 300km Range Of Reference Station Spacing

Product Description

PandaNRTK is a comprehensive software platform providing global BeiDou/GNSS high-precision “Positioning, Navigation, and Timing" (PNT) integration, with operational capabilities spanning regional to global scales. This platform integrates reference station network management, Space-time reference frame calculation, product generation and broadcasting, and large-scale data analytics. It possesses the capability for single-cluster, thousand-station level concurrent data processing and supports 7*24 hours of uninterrupted stable operation. The platform has supported the construction of the National BeiDou Ground-Based Augmentation System and is extensively deployed in provincial and municipal station networks across more than ten regions including Hubei, Guangdong, Guizhou, and Xinjiang. It has also achieved large-scale adoption in industries such as surveying, transportation, and meteorology, providing national, provincial, and industrial users with a reliable spatiotemporal foundation offering millimeter-level, centimeter-level positioning, and nanosecond-level timing.

Core Functions:

Station Management
Regional Error Resolution
Virtual Grid Data Generation
Integrity Monitoring
Service Performance Monitoring
User Management and Product Services

System Features:

Efficient, Stable, Scalable

A single server can process real-time data streams from over 500 reference stations, supports tens of millions of user registrations and tens of thousands of concurrent user accesses, and can be flexibly scaled through distributed deployment. The system is capable of 7*24 continuous operation with service availability exceeding 99%.

Fully Independent and Controllable

Supports independent operation using the domestic BeiDou system, is compatible with mainstream receiver brands domestically and internationally, possesses complete independent intellectual property rights.

Multi-constellation Multi-frequency Data Processing

Capable of processing data from four major constellations across all frequencies, supporting the access, resolution, and broadcasting of signals from multiple systems including BeiDou, GPS, GLONASS, and Galileo.

Virtual Reference Station Service

Utilizes Virtual Reference Station technology to achieve service effects comparable to physical stations, keeping sensitive raw observation data within the internal network and only broadcasting encrypted virtual data, promoting large-scale internet-based applications.

Distributed High Availability Architecture

Adopts a modular design, supports distributed deployment and dynamic scaling, and features comprehensive system operation monitoring and automatic fault recovery mechanisms.

Secure Real-time Coordinate Conversion

Supports various real-time coordinate conversion methods. Through data encryption and parameter separation technology, enables the secure real-time broadcasting of local coordinate system parameters.

Technical Parameters:

Accuracy & Availability
Real-time Precise Positioning Accuracy	Horizontal: Better than 3cm, Vertical: Better than 5cm
Navigation Accuracy	1-2m
Service Availability	>99%
Coverage Range
Real-time Precise Positioning	Within the regional reference station network (station spacing <70km) and up to 30km outside the network
Navigation Positioning	Within 300km range of reference station spacing
System Compatibility
Satellite Signals	BDS B1, B2, B3; GPS L1, L2, L5; GLONASS L1, L2; Galileo E1/E5/E6
Differential Formats	RTCM2.X, RTCM3.X, CMR, CMR+
Receiver Compatibility	Compatible with reference station and rover receivers from mainstream domestic and international manufacturers
Service & Deployment
Data Broadcast Methods	Supports differential data broadcast services via Internet, data broadcasting, radio, satellite, and other communication methods
Positioning Service Modes	Regional Single-base RTK, Network RTK, Wide-area/Regional fused Real-time Precise Point Positioning (PPP-RTK); Single-base Pseudorange Differential, Network Pseudorange Differential
System Operating Environment	Windows / Linux
